Z28001 2.8 Inch IPS LCD Display 240*320 Full View MCU Interface ST7789V IC

  • Size: 2.8 inch

  • Resolution: 240*320

  • Interface: MCU

  • View Angle: IPS

  • Brightness: 350 cd/m²

  • Touch Panel: Support CTP/RTP

  • Supply Type: Factory/Manufacturer

  • Certification: ISO9001, IATF16949, ROHS, REACH

Request A Quote
2.8 inch display
2.8 inch display
2.8 inch lcd display
2.8 inch lcd display module
2.8 inch lcd tft display
2.8 inch mcu interface display
2.8 lcd display
2.8 lcd
2.8 display

Overview of Z28001 2.8 Inch IPS LCD Display 240*320 Full View MCU Interface ST7789V IC

1

Z28001 is a color active matrix thin film transistor (TFT) liquid crystal display (LCD) with 240*320 resolution. IPS (In-plane Switching) technique make this 2.8" LCD module have a wider view angle. This wholesale LCD display module is built-in ST7789V driver IC. This a-Si TFT LCD module come with MCU interface, 350 cd/m² brightness.

2

If you have special requirement, like drive IC interface, FPC, touch panel, backlight etc, as a custom LCD display supplier, we can also customize for you.

3

Our display module factory carry out ISO 9001: 2015 and IATF16949: 2016 quality standard system strictly, all the LCD display passed ROHS, REACH Certification.

4

The 2.8 inch LCD screen is medical oximeter, cosmetic instrument, household appliance, translator, music player, smart home, industry, etc.

Specifications of 2.8 Inch IPS LCD Display 240*320 Full View MCU Interface ST7789V IC


Item

Main Display

Unit

Number of Pixels

240 * RGB * 320

Pixel

LCM Outline Dimension

47.4 (W) * 65.95 (H) * 2.18 (T)

mm

LCD Outline Dimension

46.2 (W) * 64.75 (H) * 0.8 (T)

mm

Active Area

43.2 * 57.6

mm

Pixel Pitch

0.180 * 0.180

mm

Display Mode

Normal Black


Pixel Arrangement

R.G.B Vertical Stripe


Viewing Direction

Free


Color Configuration

RGB


LCD Transmittance

Typ: 3.9%


LCD Contrast Ratio

Typ: 800; Min: 600


FPC Version

Z28001-P30 V1


Interface

MCU


Operating Temperature

-20℃ ~ 70℃


Storage Temperature

-30℃ ~ 80℃


Backlight arrangement

LED / 6 Parallel


Luminance

-


Weight

-



LCM-Pin Assignments of 2.8 Inch IPS LCD Display 240*320 Full View MCU Interface ST7789V IC


PIN NO.

PIN DEF.

FUNCTION DES.

1

LED-A

POWER SUPPLY+ FOR BACKLIGHT

2

LED-K

POWER SUPPLY- FOR BACKLIGHT CATHODE

3

GND

Ground

4

VDD

POWER SUPPLY (3.3V）

5

VDDI

POWER SUPPLY (1.8V）

6

GND

Ground

7

B17

MCU parallel interface data bus.

8

B16

MCU parallel interface data bus.

9

B15

MCU parallel interface data bus.

10

B14

MCU parallel interface data bus.

11

B13

MCU parallel interface data bus.

12

B12

MCU parallel interface data bus.

13

B11

MCU parallel interface data bus.

14

B10

MCU parallel interface data bus.

15

B7

MCU parallel interface data bus.

16

B6

MCU parallel interface data bus.

17

B5

MCU parallel interface data bus.

18

B4

MCU parallel interface data bus.

19

B3

MCU parallel interface data bus.

20

B2

MCU parallel interface data bus.

21

B1

MCU parallel interface data bus.

22

B0

MCU parallel interface data bus.

23

GND

Ground

24

RD

Read strobe signal.

25

WR

Write strobe signal.

26

RS

Ground

27

CS

Chip selection signal.

28

IM0

IM0 0, 16 bit MCU (B0-B7, B10-B17)

IM0 1, 8 bit MCU (B10-B17), B0-B7 connect GND

29

RESET

Reset Signal pin (1.8V）

30

GND

Ground


Mechanical Drawing of 2.8 Inch IPS LCD Display 240*320 Full View MCU Interface ST7789V IC
