Z40046 4 Inch LCD Screen 480*800 400nits Brightness JD9161Z Driver 40PIN MIPI

  • Size: 4 inch

  • Resolution: 480*800

  • Active Area: 51.84*86.40mm

  • Interface: MIPI

  • View Angle: IPS

  • Brightness: 400 cd/m²

  • Touch Panel: Support CTP/RTP

  • Supply Type: Factory/Manufacturer

  • Certification: ISO9001, IATF16949, ROHS, REACH

4 inch lcd screen
4 inch lcd screen
4 inch lcd screen wholesale
4 inch lcd screen manufacturer
4 inch lcd screen bulk
4 inch lcd screen company
4 inch lcd screen
4 inch lcd screen
4 inch lcd screen company
4 inch lcd screen bulk
4 inch lcd screen
4 inch lcd screen wholesale
4 inch lcd screen
4 inch lcd screen
4 inch lcd screen wholesale
4 inch lcd screen bulk
4 inch lcd screen manufacturer
4 inch lcd screen manufacturer bulk
4 inch lcd screen company
4 inch lcd screen company
4 inch lcd screen bulk
4 inch lcd screen manufacturer
4 inch lcd screen
4 inch lcd screen wholesale
4 inch lcd screen manufacturer
4 inch lcd screen bulk
4 inch lcd screen company

Overview of Z40046 4 Inch LCD Screen 480*800 400nits Brightness JD9161Z Driver 40PIN MIPI

1

Z40046 is a color active matrix thin film transistor (TFT) liquid crystal display (LCD) with 480*800 resolution. IPS (In-plane Switching) technique make this 4" LCD module have a wider view angle. This square LCD display is built-in JD9161Z-JN driver IC. This a-Si TFT LCD module come with MIPI interface, 400 cd/m² brightness.

2

If you have special requirements, like drive IC interface, FPC, touch panel, backlight, etc, as a custom LCD screen manufacturer, we can also customize for you.

3

As one of the wholesale touch screen factories,our factory carry out ISO 9001: 2015 and IATF16949: 2016 quality standard system strictly, all the LCD display passed ROHS, REACH Certification.

4

The 4 inch LCD screen is widely used in visual doorbell, E-wallet, POS, game player, cosmetic instrument, household appliance, QRcode scanner, Infrared temperature, translator, smart home, industry handheld, outdoor, HMI, etc.

Specifications of 4 Inch LCD Screen 480*800 400nits Brightness JD9161Z Driver 40PIN MIPI


No.

Item

Specification

Unit

1

Display Size (Diagonal)

3.97

inch

2

Display Resolution

480 (H) × RGB × 800 (V)

pixels

3

Pixel Pitch

108 (H) × 108 (V)

um

4

LCM Outline Dimension

(Without FPC)

57.14 (W) × 96.85 (H) ×2.15 (T)

mm

5

LCD Outline Dimension

54.74 (W) × 93.35 (H) × 0.4 (T)

mm

6

LCD Active Area

51.84 (W) × 86.40 (H)

mm

7

View Direction (Gray Inversion)

FULL VIEW

-

8

Driver IC

JD9161Z-JN

-

9

Pixel Arrangement

RGB-Stripe

-

10

Display Mode

Normal Black

-

11

Pixel driving Element

a-Si TFT

-

12

LCD Transmittance

Typ.: 4.03% Min: 3.4%

-

13

LCD Contrast Ratio

Typ.: 800 Min: 600

-

14

FPC Version

Z40037-SPC008W V1

-

15

Interface

MIPI

-

16

Operating Temperature

-20°C~ 70°C

-

17

Storage Temperature

-30°C~ 80°C

-

18

Backlight Arrangement

LED/4 Series 2 Parallel (8 lights in total)

-

19

Luminance

400

nit

20

Weight

0.019

kg


Interface Definition Description of 4 Inch LCD Screen 480*800 400nits Brightness JD9161Z Driver 40PIN MIPI


PIN NO.

PIN DEF.

FUNCTION DESC.

1-3

LEDA

POWER SUPPLY- FOR BACKLIGHT ANODE

4-7

NC

No Connection

8-10

LEDK

POWER SUPPLY- FOR BACKLIGHT CATHODE

11

GND

Ground

12

NC

No Connection

13

GND

Ground

14-15

NC

No Connection

16

GND

Ground

17

DSI_D1P

Positive MIPI differential data input

18

DSI_D1N

Negative MIPI differential data input

19

GND

Ground

20

DSI_CLKP

Positive MIPI differential CLOCK input

21

DSI_CLKN

Negative MIPI differential CLOCK input

22

GND

Ground

23

DSI_D0P

Positive MIPI differential data input

24

DSI_D0N

Negative MIPI differential data input

25

GND

Ground

26-27

NC

No Connection

28

GND

Ground

29

LCDID1

LCM ID PIN

30

LCD_RST

LCM RESET PIN (1.8V)

31

LCDID2

LCM ID PIN

32

IOVDD

I/O POWER SUPPLY (1.8V)

33-34

LCD_VCC

POWER SUPPLY (2.8V)

35

GND

Ground

36

NC

No Connection

37

GND

Ground

38

NC

No Connection

39

LCDID3

LCM ID PIN

40

NC

No Connection


Mechanical Drawing of 4 Inch LCD Screen 480*800 400nits Brightness JD9161Z Driver 40PIN MIPI


Mechanical Drawing of 4 Inch LCD Screen 480*800 400nits Brightness JD9161Z Driver 40PIN MIPI
