Z80035-P39 High Definition 8 Inch TFT LCD Display 1200*1920 800nits 39PIN MIPI Interface

  • Size: 8 inch

  • Resolution: 1200*1920

  • Active Area: 107.64 *172.22 mm

  • Interface: MIPI

  • View Angle: IPS

  • Brightness: 800 cd/m²

  • Touch Panel: Support CTP/RTP

  • Supply Type: Factory/Manufacturer

  • Certification: ISO9001, IATF16949, ROHS, REACH

Request A Quote
8 inch 1200 1920 lcd
8 inch 1200 1920 lcd
8 tft lcd
8 inch 1200 1920 display
8 inch tft lcd

Overview of Z80035-P39 High Definition 8 Inch TFT LCD Display 1200*1920 800nits 39PIN MIPI Interface

1

Z80035 is a color active matrix thin film transistor (TFT) liquid crystal display (LCD) with 1200*1920 resolution. IPS (In-plane Switching) technique make this 8" square TFT  LCD module have a wider view angle. This a-Si TFT LCD module come with MIPI interface, 800cd/m² brightness.

2

If you have special requirements, like drive IC, interface, FPC, touch panel, brightness, color, backlight, touch panel, etc, we can provide custom LCD display module for you.

3

As a LCD screen factory in China, our factory carry out ISO 9001: 2015 and IATF16949: 2016 quality standard system strictly, all the LCD display passed ROHS, REACH Certification.

4

The 8 inch LCD screen is widely used in Medical, visual doorbell, Vending, learning mechine, ventilator, oscilloscope, kitchen, household appliance, smart home, industry, handheld, outdoor, E-bike, Vehicle, projector, 3D printer, audio device, robot, electric scale, navigation, dashboard, elevator advertising, robot, etc.

Specifications of High Definition 8 Inch TFT LCD Display 1200*1920 800nits 39PIN MIPI Interface


No.

Item

Specification

Unit

1

Display Size (Diagonal)

8.0

inch

2

Display Resolution

1200 (H) × RGB × 1920 (V）

pixels

3

Pixel Pitch

89.7 (H) × 89.7 (V）

um

4

LCM Outline Dimension

(Without FPC）

122.44 (W) × 183.67 (H) × 2.62 (T)

mm

5

CTP Outline Dimension

(Without FPC）

N/A

mm

6

LCD Outline Dimension

111.64 (W) × 180.28 (H) × 0.8 (T)

mm

7

LCD Active Area

107.64 (W) × 172.22 (H）

mm

8

View Direction (Gray Inversion)

FULL VIEW

-

9

Driver IC

OTA7290B

-

10

Pixel Arrangement

RGB-Stripe

-

11

Display Mode

Normal Black

-

12

Pixel driving Element

a-Si TFT

-

13

LCD Transmittance

/

-

14

LCD Contrast Ratio

Typ.: 1200 Min: 800

-

15

FPC Version

Z80035-P39 V1

-

16

Interface

MIPI

-

17

Operating Temperature

-20°C~ 70°C

-

18

Storage Temperature

-30°C~ 80°C

-

19

Backlight Arrangement

LED/6 Series 6 Parallel (36 lights in total)

-

20

Luminance

Typ.:800

nit

21

Weight

/

kg


Interface Definition Description of High Definition 8 Inch TFT LCD Display 1200*1920 800nits 39PIN MIPI Interface


PIN NO.PIN DEF.FUNCTION DESC.
1VDDPOWER SUPPLY
2VDDIOI/O POWER SUPPLY
3RSTBLCM RESET PIN
4NCNo Connection
5GNDGround
6MIPI_D3NNegative MIPI differential data input
7MIPI_D3PPositive MIPI differential data input
8GNDGround
9MIPI_D2NNegative MIPI differential data input
10MIPI_D2PPositive MIPI differential data input
11GNDGround
12MIPI_D1NNegative MIPI differential data input
13MIPI_D1PPositive MIPI differential data input
14GNDGround
15MIPI_D0NNegative MIPI differential data input
16MIPI_D0PPositive MIPI differential data input
17GNDGround
18MIPI_CLKNNegative MIPI differential CLOCK input
19MIPI_CLKPPositive MIPI differential CLOCK input
20GNDGround
21-22LEDKPOWER SUPPLY- FOR BACKLIGHT CATHODE
23-24LEDAPOWER SUPPLY- FOR BACKLIGHT ANODE
25GNDGround
26IDLCM ID PIN
27TETearing Effect PIN
28NCNo Connection
29GNDGround
30NCNo Connection
31GNDGround
32CTP_VDDTP POWER SUPPLY
33NCNo Connection
34CTP_INTTP Interrupt PIN
35CTP_RSTTP Reset PIN
36CTP_SDATP I2C data (SDA) data input (MOSI)
37CTP_SCLTP I2C clock (SCL) clock (SCLK)
38NCNo Connection
39GNDGround
RESET voltage should be consistent with VDDI voltage, or there probably is black screen fault when power on.


Mechanical Drawing of High Definition 8 Inch TFT LCD Display 1200*1920 800nits 39PIN MIPI Interface


Mechanical Drawing of High Definition 8 Inch TFT LCD Display 1200*1920 800nits 39PIN MIPI Interface
